This product is a radially outer 12-pole magnetized ring magnet made of sintered ferrite. It is mainly used in air conditioners, permanent magnet DC motors, automotive oil pump motors, magnetic induction tachometer motors,
The multi-pole magnetic ring is to use a special magnetizer to magnetize the magnetic ring with the required number of pole pairs on the hard magnetic ring material. The magnetization effect is related to the magnetic ring material used and the performance of the magnetizer. The size of the magnetic energy product and the The hysteresis attenuation is related to the above situation. Welcome to inquire about the price and sample.
Courage Magnet supports customizing sintered ferrite rotor, ferrite radial multipole rotor magnet, pump motor rotor, water flowmeter rotor magnet, micro motor rotor, quality factory, strength speaking, welcome to purchase wholesale!
Go to the Multipole Ring Ferrites section to select more sizes.
12-pole ring magnet of the same material;
Ferrite grade, sintered ferrite magnetic property parameter table
NdFeB magnet grade, Sintered neodymium magnet performance grade parameter table
Neodymium(Ndfeb) Magnet Material Safety Data Sheet
Sintered Ferrite Material Safety Data Sheet Pdf
Magnetic properties grade parameters of smco rare earth magnets
This sample is a speed measurement magnet, an AC geared motor multi-pole ring magnet, made of sintered ferrite, the magnetization method is radial 24 poles, the magnet size is 22.5mm in outer diameter, 12mm in inner diameter, and 6.5mm in thickness. Qi magnet manufacturers provide,...
You are now viewing this is a bonded molded NdFeB magnet, ring shape, ring OD 38mm, hole 29mm, height 20mm, surface black epoxy coating, the magnetization is through the radial multi-pole magnetization, there are 10 poles, 5 N-pole, 5 S-pole....
You are now seeing the specifications of this magnet ring OD 13mm, bore diameter 8mm, thickness of 3.5mm, the surface of the black epoxy, due to the reason of the photo may look like a ferrite, the actual bonded ring magnets, suitable for a variety of types of motor, sensor, and electric appliances....
This is a large-sized multi-pole ring magnet, which was originally shot by Chinese magnet supplier Courage Xiaofu. If you see it in other websites, it is completely copied from us. The size of this magnet is 70.2mm in outer diameter, 51.83mm in inner diameter, and 28mm in thickness (height). The largest magnetic surface is on the outer side of the ring...
This is a multi-pole neodymium magnetic ring made of bonded NdFeB material, hollow cylindrical with 6 poles, radial distribution of 3N3S, outer diameter 12mm, center hole 8mm, height 20mm, surface magnetic strength of about 1750 gauss...
Looking for suppliers of radial 16 pole ring magnet and multi-level magnetic ring, welcome to contact carrich magnet manufacturers in China. We have more than 10 years of experience in the motor magnet industry. Our products have many specifications and good performance, which are highly praised by customers at home and abroad. We welcome to provide specifications, samples and batch prices....
This is a 6-pole ring magnet made of injection molded ferrite, with an outer diameter of 9.5mm, an inner hole of 1mm, a thickness of 2mm, single-sided 6-pole magnetization, 3 N poles and 3 S poles. It is mainly used for Hall encoder....
This is a single-sided multi-pole magnetized ring magnet, only one side is magnetic, there are 4 poles on the surface, 2 N-pole, 2 S-pole, the material is injection molded ferrite, the outer diameter size of 17mm, the thickness of 4.5mm...
