Product name: permanent magnet motor 8 pole radial ring neodymium magnet
Specification: Outer diameter 6.5mm, inner diameter 3mm, height 3.7mm
Material: Bonded neodymium magnets
Magnetization: Radial 8 pole (4N4S)
Shape: Ring (inner hole D shape)
Type of magnet: Motor permanent magnet
Appearance: Black
Coating: black epoxy
Magnetic strength: 2200 Gauss
Packing: carton + foam + magnetic separator
Supply area: world wide
Delivery time: 10-35 days
Our company has more specifications bonded neodymium magnet ring, which can save mold costs for you with a high probability. Axial or radial or oblique Angle magnetization can be used to support personalized customization. If you need which specifications, please send us to inquire mold for you and offer.
