There are several measurements that affect the strength of the permanent magnet, which often seems confusing. Magnetic field strength (residual magnetism), resistance to demagnetization (coercivity) and tensile force are usually summarized as strength, all of which are ideal properties of permanent magnets.
The single main indicator of the strength of a permanent magnet is its maximum energy product measured in Megagauss Oersteds (MGOe). The higher the maximum energy product value, the larger the magnetic field generated by the magnet in a particular application.
The maximum energy product, also called BHmax, is calculated by multiplying the magnet's remanence (Br) and coercive force (Hc). The strongest magnets in the world are neodymium magnets. They come in different grades, but each grade has a convenient name that allows you to immediately judge which magnet is stronger. Commercially available neodymium magnets range from N35 to N52; the number after the letter "N" represents the maximum energy product of the magnet.
The individual properties of magnets will change due to temperature. Certain types of magnets perform better than others at high temperatures, such as Alnico magnets and Samarium Cobalt magnets.
In a high temperature environment, the five magnetic materials lose their magnetism at different speeds and have different maximum operating temperatures. If the temperature exceeds the maximum operating temperature of a single class, it will be permanently demagnetized.
In short, through proper maintenance and storage of magnets, permanent magnets can maintain their strength forever. However, if it is exposed to certain conditions, it will also lose its "permanent" magnetism. Ultimately, determining whether a permanent magnet will lose its magnetism over time depends on its specific application.
How to measure the magnetic field strength of a magnet?
You can use a Gauss meter to determine the strength of a magnet, you can use a Tesla meter to measure the magnetic field, a flux meter to measure the magnetic flux, or a tensile tester.
Permanent magnets that our company can provide;
Articles related to the strength of permanent magnets;
What is the magnetic strength of the N52 super magnet?
Introduction to the strength of ceramic ferrite
Will the magnet coating (plating) affect the magnetic strength of the magnet?
This product is round ferrite magnet with a diameter of 9mm and a thickness of 3mm, the performance class is Y30, magnetized in the thickness direction, without electroplating protective layer, the magnetic force is usually 700-1000gs, the working temperature is -40°C to +250°C, Suitable for sensors, suction parts, electrical appliances, Hall induction....
This is a very small size rectangular block magnet with galvanized surface, 3mm length, 1.5mm width and height, with very fine tolerance, magnetized by lengthwise direction, mainly used in precision electronics, instrumentation, please contact us if you need to buy....
Flat magnets can be flat square magnets or round magnets. Today's sample is a flat rectangular magnet, with a length of 20mm, a width of 10mm, a thickness of 1.5mm, and a zinc coating on the surface. Thickness magnetization is used for thin workpieces. The use of this relatively flat neodymium rectangular magnet requires special attention....
Looking for suppliers of radial 16 pole ring magnet and multi-level magnetic ring, welcome to contact carrich magnet manufacturers in China. We have more than 10 years of experience in the motor magnet industry. Our products have many specifications and good performance, which are highly praised by customers at home and abroad. We welcome to provide specifications, samples and batch prices....
This is a dedicated to screwdrivers, drills on top of the ring magnet, the material is rare earth neodymium, N38 grade, outer diameter 15mm, height 10mm. hole diameter 7mm, the use of very simple, is to set the magnetic ring in the screwdriver (screwdriver head) on top of the purchase of the hole is recommended to be larger 1mm....
Product name: 9.5mm diameter thickness 1.5mm neodymium intense magnetic，Type of magnet: permanent magnet，Magnet shape: Round，Magnet class: n45，Tolerance: ±0.05，Coating: conventional nickel copper nickel，Pull: About 1.6 pounds，Magnetic strength: about 2200 Gauss....
This is a C8 grade ceramic ferrite block rectangle, with white marks made according to the customer's requirements. The magnet size is 13mm long, 11mm wide and 10mm thick. If you are interested in such a magnet, you can contact us to provide you with samples, prices,...
This is a 6-pole ring magnet made of injection molded ferrite, with an outer diameter of 9.5mm, an inner hole of 1mm, a thickness of 2mm, single-sided 6-pole magnetization, 3 N poles and 3 S poles. It is mainly used for Hall encoder....
